X-Ray Machine

Overview

PLAN IT Inspection Systems' X-Ray Systems provide advanced inspection capabilities to detect a wide range of contaminants, including metal, glass, stone, and stick fragments, while also identifying packaging defects.

With high-performance imaging technology and automated rejection options, these systems help ensure product quality, improve production reliability, and support consistent quality assurance throughout the manufacturing process.

Speeds (Up to)

Speed up to 60 m/min

Features

  • Adjustable Conveyor Height
    Flexible conveyor height adjustment up to 800mm to accommodate different production line configurations.
  • HMI Touchscreen
    Large, user-friendly touchscreen interface for simplified operation, monitoring, and system control.
  • Advanced Algorithm Software
    Intelligent X-Ray inspection software designed to improve detection accuracy and optimize inspection performance.

Specifications

Max Load

Up to 30kg

X Radiation Source

Up to VJ, max100Kv/350W

Temperature

0–45°C with cooler equipped

IP Rate

IP66 tunnel / IP55 whole system incl. dehumidifier

Best Sensitivity

SS ball 0.5mm, SUS wire 0.4*2mm, Glass/Ceramic 1.5mm

X-Ray Leakage

<1 μSv/h

Detector Pixel Size

0.4mm/0.8mm

Packaging Type

Pouches

Jars

Packaging Dimensions

Max Detection (mm): 600mm
